Polyimide is a polymer thermoset plastic that has exceptional thermal stability, chemical resistance, and tensile strength.

These characteristics make polyimide an ideal material for high-performance medical applications. The tubing is lightweight, flexible, and resistant to heat and chemical interaction.

Shelves filled with cylindrical containers, organized in rows, showcasing various colors and materials, likely used for storage or inventory purposes.
Various types of yellow and black tubing are arranged vertically against a blue background, showcasing materials used for piping or insulation.
A technician examines fiber optic cables with magnifying glasses, wearing gloves and a lab coat, showcasing precision in telecommunications work.
Close up of the hands with stent
Various dipsticks for measuring fluid levels are displayed, showcasing different materials and designs. Key for understanding fluid measurement tools.
PTFE Coated Mandrels & Wire

Reinforced Tubing

Specifications

  • The most common braid/coil material is 304V stainless steel.
  • Both round and flat wires are available. Common wire sizes:
    • Round wire 0.0010″ to 0.004″
    • Flat wire 0.0005″ x 0.0025″ and larger
  • “PIC” count = per inch crosses (Braid)
  • “WPI” count = wraps per inch (Coil)
  • Higher PIC counts improve flexibility, while a lower PIC count increases longitudinal stiffness
  • The PIC count can be varied within a specific length to provide variable flexibility. This can also be achieved via selective laser removal of OD layers or variable durometer reflows.
  • Selective laser removal of Polyimide top-layers increases flexibility and helps in secondary processes & assembly
  • Axial reinforcement provides added tensile strength and minimized elongation
Four distinct cable types are displayed: a black braided cable, a metallic mesh cable, a two-tone yellow and orange cable, and another black braided cable. Each represents different material and design for electrical applications.
